Copper

Advent Research Materials Ltd are a leading global supplier of Copper (Cu) in foil, sheet, wire, insulated wire, rod, tube, ribbon and mesh/gauze form in various different quantities.

Copper is one of the few metals that is found in its pure form as a un-compounded mineral. As a result it was known by some of the oldest civilizations on record. Since then it has been used extensively in both its pure and alloyed form.

Copper is a malleable and ductile metal with reddish / brownish colour and exceptional electrical and thermal conductivity, second only to silver. Coppers mechanical properties allow it to be easily be drawn into wire form, along with coppers excellent electrical conductivity and most importantly coppers relatively low cost has resulted in its extensive use in many different types of electrical work. Coppers’ high thermal conductivity also makes it useful as heat sinks or heat exchangers.

For many applications pure copper is too soft. As a result copper is used in many different alloy combinations, such as brass (copper-zinc) and bronze (copper-tin). Copper and its alloys have numerous applications, such as piping, architecture and industry, household products etc.. Copper is also one of the major coinage metals.

Further properties of Copper have been outlined below:

Copper Melting point 1084.62 °C
Copper Density 8920 kgm^-3
Copper Young’s modulus 130 GPa
Copper Poisson’s ratio 0.34
Copper Electrical Resistivity 1.72 x 10^-8 Wm
Copper Thermal Conductivity 400 W m^-1 K^-1

Showing 156 product lines

Filter

Copper Foil

Line Number & Material	Thickness	Purity	Description
CU1379 Copper Foil	0.005 mm	99.997+%	Temper hard. Quality NOT Light-Tigtht.	View item
CU1380 Copper Foil	0.005 mm	99.997+%	Temper hard. Quality Light-Tigtht.	View item
CU1291 Copper Foil	0.007 mm	99.99+%	Temper hard OFHC C103. Coil Width 10mm.	View item
CU1293 Copper Foil	0.007 mm	99.9%	Temper hard.	View item
CU1376 Copper Foil	0.010 mm	99.9%	Temper hard.	View item
CU1377 Copper Foil	0.010 mm	99.99%	Temper hard OFHC C110.	View item
CU1378 Copper Foil	0.010 mm	99.999%	Temper as rolled.	View item
CU1287 Copper Foil	0.0125 mm	99.9%	Temper hard. Coil Width 10mm.	View item
CU1288 Copper Foil	0.0125 mm	99.99+%	Temper hard OFHC C103. Coil Width 10mm.	View item
CU1296 Copper Foil	0.0125 mm	99.9%	Temper hard. Quality Light-Tight.	View item
CU1295 Copper Foil	0.0125 mm	99.995%	Temper as rolled.	View item
CU1297 Copper Foil	0.017 mm	99.95%	Electrodeposited.	View item
CU1300 Copper Foil	0.025 mm	99.9%	Temper half hard. Quality Light-Tight.	View item
CU1358 Copper Foil	0.025 mm	99.9%	Temper annealed. Quality Light-Tight.	View item
CU1356 Copper Foil	0.025 mm	99.99%	Temper annealed OFHC C110. Quality Light-Tight.	View item
CU1369 Copper Foil	0.025 mm	99.996+%	Temper annealed. Quality Light-Tight.	View item
CU1302 Copper Foil	0.035 mm	99.95%	Electrodeposited.	View item
CU1303 Copper Foil	0.050 mm	99.9%	Temper hard.	View item
CU1261 Copper Foil	0.050 mm	99.9%	Temper annealed.	View item
CU1333 Copper Foil	0.050 mm	99.95+%	Temper hard OFHC C103. CW008A.	View item
CU1387 Copper Foil	0.050 mm	99.99+%	Temper hard OFHC C110. CW009A.	View item
CU1260 Copper Foil	0.050 mm	99.99%	Temper annealed OFHC C110. CW009A.	View item
CU1334 Copper Foil	0.050 mm	99.9976%	Temper annealed.	View item
CU1306 Copper Foil	0.070 mm	99.95%	Electrodeposited.	View item
CU1301 Copper Foil	0.10 mm	99.9%	Temper annealed.	View item
CU1308 Copper Foil	0.10 mm	99.9%	Temper half hard.	View item
CU1329 Copper Foil	0.10 mm	99.997+%	Temper half hard.	View item
CU1305 Copper Foil	0.10 mm	99.95+%	Temper hard OFHC C103.	View item
CU1304 Copper Foil	0.10 mm	99.99%	Temper annealed OFHC C110.	View item
CU1311 Copper Foil	0.10 mm	99.998%	Temper annealed.	View item
CU1307 Copper Foil	0.105 mm	99.95%	Electrodeposited.	View item
CU1309 Copper Foil	0.125 mm	99.9%	Temper annealed.	View item
CU1349 Copper Foil	0.125 mm	99.99%	Temper annealed OFHC C110.	View item
CU1310 Copper Foil	0.125 mm	99.995%	Temper as rolled.	View item
CU1365 Copper Foil	0.15 mm	99.97%	Temper annealed.	View item
CU1312 Copper Foil	0.20 mm	99.9%	Temper half hard.	View item
CU1362 Copper Foil	0.20 mm	99.9%	Temper annealed.	View item
CU1364 Copper Foil	0.20 mm	99.99+%	Temper annealed.	View item
CU1325 Copper Foil	0.25 mm	99.9%	Temper half hard.	View item
CU1361 Copper Foil	0.25 mm	99.9%	Temper annealed Price Reduced. Oxidised with Rolling marks.	View item
CU1363 Copper Foil	0.25 mm	99.9%	Temper annealed. Coil width 305mm.	View item
CU1313 Copper Foil	0.25 mm	99.99%	Temper annealed. Coil width 305mm.	View item
CU1346 Copper Foil	0.25 mm	99.99%	Temper half hard OFHC C110. Coil width 200mm.	View item
CU1314 Copper Foil	0.25 mm	99.995%	Temper as rolled.	View item
CU1384 Copper Foil	0.3 mm	99.9%	Temper half hard. Flat sheet.	View item
CU1383 Copper Foil	0.3 mm	99.99%	Temper half hard OFHC C103. Flat sheet. O<5ppm.	View item
CU1385 Copper Foil	0.3 mm	99.996+%	Temper as rolled.	View item
CU1323 Copper Foil	0.32 mm	99.9%	Temper half hard.	View item
CU1315 Copper Foil	0.40 mm	99.9%	Temper half hard. Flat sheet.	View item
CU1318 Copper Foil	0.40 mm	99.99%	Temper half hard OFHC C103. Flat sheet. O<5ppm.	View item
CU1386 Copper Foil	0.40 mm	99.996+%	Temper as rolled.	View item
CU1326 Copper Foil	0.50 mm	99.9%	Temper half hard. Flat Sheet.	View item
CU1347 Copper Foil	0.50 mm	99.98+%	Temper half hard OFHC C103. Flat sheet. O<5ppm.	View item
CU1345 Copper Foil	0.50 mm	99.99%	Temper half hard OFHC C110.	View item
CU1316 Copper Foil	0.50 mm	99.997%	Temper as rolled.	View item

Copper Ribbon

Line Number & Material	Thickness	Purity	Description
CU1299 Copper Ribbon	0.035 mm	99.95%	Temper as rolled OFHC.	View item
CU1372 Copper Ribbon	0.25 mm	99.9%	Temper annealed.	View item

Copper Sheet

Line Number & Material	Thickness	Purity	Description
CU1332 Copper Sheet	0.9 mm	99.98+%	Temper half hard OFHC C103.	View item
CU1317 Copper Sheet	1.0 mm	99.9%	Temper half hard.	View item
CU1355 Copper Sheet	1.0 mm	99.98%	Temper half hard OFHC C103.	View item
CU1336 Copper Sheet	1.0 mm	99.99%	Temper annealed OFHC C110.	View item
CU1319 Copper Sheet	1.0 mm	99.997%	Temper as rolled.	View item
CU1367 Copper Sheet	1.0 mm	99.99%	Temper annealed. One side - Diamond Polished. Surface finish <0.01 Ra (µm).	View item
CU1324 Copper Sheet	1.6 mm	99.9%	Temper half hard.	View item
CU1340 Copper Sheet	1.6 mm	99.99%	Temper half hard OFHC C110.	View item
CU1341 Copper Sheet	1.6 mm	99.997%	Temper as rolled.	View item
CU1331 Copper Sheet	2.0 mm	99.9%	Temper half hard.	View item
CU1321 Copper Sheet	2.0 mm	99.98+%	Temper half hard OFHC C103.	View item
CU1322 Copper Sheet	2.0 mm	99.997%	Temper as rolled.	View item
CU1370 Copper Sheet	3.0 mm	99.99+%	Temper half hard OFHC C103.	View item
CU1342 Copper Sheet	3.15 mm	99.9%	Temper half hard.	View item
CU1335 Copper Sheet	3.15 mm	99.99%	Temper annealed OFHC C110.	View item
CU1339 Copper Sheet	3.15 mm	99.997%	Temper as rolled.	View item

Copper Plate

Line Number & Material	Thickness	Purity	Description
CU1350 Copper Plate	4.0 mm	99.9%	Temper half hard.	View item
CU1344 Copper Plate	6.0 mm	99.9%	Temper half hard. Tolerance on size +/-2mm.	View item
CU1351 Copper Plate	6.0 mm	99.99%	Extruded flat bar OFHC C110. Tolerance on size +/-2mm.	View item
CU1338 Copper Plate	6.35 mm	99.99%	Temper half hard OFHC C110.	View item
CU1343 Copper Plate	6.35 mm	99.997%	Temper as rolled.	View item
CU1262 Copper Plate	12.5 mm	99.95+%	Temper hard OFHC C103.	View item

Copper Sputtering target / Disc

Line Number & Material	Thickness	Purity	Description
CU1354 Copper Sputtering target / Disc	6.35 mm	99.997%	-	View item

Copper Wire

Line Number & Material	Diameter	Purity	Description
CU5111 Copper Wire	0.02 mm	99.99%	Temper hard OFHC C110.	View item
CU5162 Copper Wire	0.025 mm	99.9%	Temper hard.	View item
CU5165 Copper Wire	0.025 mm	99.99%	Temper hard OFHC C110.	View item
CU5161 Copper Wire	0.04 mm	99.9%	Temper annealed.	View item
CU5124 Copper Wire	0.04 mm	99.99%	Temper annealed OFHC C110.	View item
CU5101 Copper Wire	0.05 mm	99.9%	Temper annealed.	View item
CU5102 Copper Wire	0.05 mm	99.99%	Temper annealed OFHC C110.	View item
CU5155 Copper Wire	0.064 mm	99.9%	Temper annealed.	View item
CU5125 Copper Wire	0.064 mm	99.99%	Temper annealed OFHC C110.	View item
CU5096 Copper Wire	0.064 mm	99.99%	Temper annealed OFHC C110. 7 concentric strands 0.064mm. o.d. of 7 strands 0.193mm.	View item
CU5156 Copper Wire	0.075 mm	99.9%	Temper annealed.	View item
CU5126 Copper Wire	0.075 mm	99.99%	Temper annealed OFHC C110.	View item
CU5157 Copper Wire	0.1 mm	99.9%	Temper annealed.	View item
CU5127 Copper Wire	0.1 mm	99.99%	Temper annealed OFHC C110.	View item
CU5139 Copper Wire	0.125 mm	99.9%	Temper annealed.	View item
CU5140 Copper Wire	0.125 mm	99.99%	Temper annealed OFHC C110.	View item
CU5104 Copper Wire	0.125 mm	99.998%	Temper annealed.	View item
CU5141 Copper Wire	0.15 mm	99.9%	Temper annealed.	View item
CU5142 Copper Wire	0.15 mm	99.99%	Temper annealed OFHC C110.	View item
CU5158 Copper Wire	0.178 mm	99.9%	Temper annealed.	View item
CU5128 Copper Wire	0.178 mm	99.99%	Temper annealed OFHC C110.	View item
CU5143 Copper Wire	0.2 mm	99.9%	Temper annealed.	View item
CU5144 Copper Wire	0.2 mm	99.99%	Temper annealed OFHC C110.	View item
CU5105 Copper Wire	0.25 mm	99.9%	Temper annealed.	View item
CU5123 Copper Wire	0.25 mm	99.99%	Temper annealed OFHC C110.	View item
CU5106 Copper Wire	0.25 mm	99.997%	Temper annealed.	View item
CU5159 Copper Wire	0.3 mm	99.9%	Temper annealed.	View item
CU5138 Copper Wire	0.3 mm	99.99%	Temper annealed OFHC C110.	View item
CU5160 Copper Wire	0.4 mm	99.9%	Temper annealed.	View item
CU5154 Copper Wire	0.4 mm	99.99%	Temper annealed OFHC C110.	View item
CU5107 Copper Wire	0.5 mm	99.9%	Temper annealed.	View item
CU5145 Copper Wire	0.5 mm	99.99%	Temper annealed OFHC C110.	View item
CU5108 Copper Wire	0.5 mm	99.997%	Temper annealed.	View item
CU5146 Copper Wire	0.75 mm	99.9%	Temper Annealed.	View item
CU5147 Copper Wire	0.75 mm	99.99%	Temper annealed OFHC C110.	View item
CU5148 Copper Wire	0.75 mm	99.998%	Temper Annealed.	View item
CU5109 Copper Wire	1 mm	99.9%	Temper annealed.	View item
CU5114 Copper Wire	1 mm	99.95+%	Temper annealed OFHC C103.	View item
CU5149 Copper Wire	1 mm	99.99%	Temper annealed OFHC C110.	View item
CU5110 Copper Wire	1 mm	99.998%	Temper annealed.	View item
CU5119 Copper Wire	1.5 mm	99.9%	Temper annealed.	View item
CU5117 Copper Wire	1.5 mm	99.99%	Temper annealed OFHC C110.	View item
CU5118 Copper Wire	1.5 mm	99.999%	Temper annealed. CU5N.	View item
CU5115 Copper Wire	2 mm	99.9%	Temper annealed.	View item
CU5113 Copper Wire	2 mm	99.99%	Temper annealed OFHC C110.	View item
CU5112 Copper Wire	2 mm	99.996%	Temper annealed.	View item

Copper Wool

Line Number & Material	Diameter	Purity	Description
CU5166 Copper Wool	0.05 mm	99.99%	Temper annealed.	View item

Copper Wire - Straight Cut Lengths

Line Number & Material	Diameter	Purity	Description
CU5167 Copper Wire - Straight Cut Lengths	2 mm	99.99%%	Temper annealed OFHC C110. Condition Deburred.	View item

Copper Insulated Wire

Line Number & Material	Bare Wire Diameter	Purity	Description
CU5097 Copper Insulated Wire	0.008 mm	99.99%	Clad with Borosilicate glass.	View item
CU5121 Copper Insulated Wire	0.025 mm	99.9%	Temper annealed. 2 coatings. 1st coat Polymesteride. Top coat Polyamide.	View item
CU7500 Copper Insulated Wire	0.0282 mm	99.9%	Temper annealed. 49 AWG. Polyimide Insulated.	View item
CU5122 Copper Insulated Wire	0.05 mm	99.9%	Temper annealed. 1st coat Polymesteride. Top coat Polyamide-Imide.	View item
CU5151 Copper Insulated Wire	0.05 mm	99.99%	Temper annealed OFHC C110. Quadruple PTFE insulated.	View item
CU7501 Copper Insulated Wire	0.0508 mm	99.9%	Temper annealed AWG 44. Polyimide Insulated. Single layer.	View item
CU5120 Copper Insulated Wire	0.064 mm	99.99%	Temper annealed OFHC C110. Quadruple PTFE clear coating. 7 concentric strands ø 0.064mm.	View item
CU7502 Copper Insulated Wire	0.079 mm	99.9%	Temper annealed 40 AWG. Polyimide Insulated. Single layer.	View item
CU5168 Copper Insulated Wire	0.1 mm	99.9%	Temper annealed. Formvar Insulated. Single layer.	View item
CU5169 Copper Insulated Wire	0.1016 mm	99.9%	Temper annealed 38 AWG. Polyimide-ML Insulated. Single layer.	View item
CU7503 Copper Insulated Wire	0.127 mm	99.9%	Temper annealed 36 AWG. Polyimide Insulated. Single layer.	View item
CU7504 Copper Insulated Wire	0.16 mm	99.9%	Temper annealed 34 AWG. Polyimide Insulated. Single layer.	View item
CU7505 Copper Insulated Wire	0.203 mm	99.9%	Temper annealed 32 AWG. Polyimide Insulated. Single layer.	View item
CU5150 Copper Insulated Wire	0.25 mm	99.99%	Temper annealed OFHC C110. Quadruple PTFE insulated.	View item
CU7506 Copper Insulated Wire	0.254 mm	99.9%	Temper annealed 30 AWG. Polyimide Insulated. Single layer.	View item

Copper Plated Wire

Line Number & Material	Bare Wire Diameter	Purity	Description
CU5136 Copper Plated Wire	0.15 mm	99.9%	Temper annealed. Silver plated 99.95+%.	View item
CU5137 Copper Plated Wire	0.5 mm	99.9%	Temper annealed. Silver plated 99.95+%.	View item

Copper WOVEN Mesh / Gauze

Line Number & Material	Dimensions	Purity	Description
CU5152 Copper WOVEN Mesh / Gauze	60 mesh per inch	99.9%	558/cm.sq. Plain weave. Wire diameter 0.16mm. Aperture: 0.263 mm Open Area: 39%	View item
CU5116 Copper WOVEN Mesh / Gauze	50 mesh per inch	99.9%	388/cm.sq. Plain weave. Wire diameter 0.18mm. Aperture: 0.33 mm Open Area: 42%	View item
CU5134 Copper WOVEN Mesh / Gauze	40 mesh per inch	99.9%	248/cm.sq. Plain weave. Wire diameter 0.224mm. Aperture: 0.41 mm Open Area: 42%	View item
CU5153 Copper WOVEN Mesh / Gauze	40 mesh per inch	99.9%	248/cm.sq. Plain weave. Wire diameter 0.25mm. Aperture: 0.385 mm Open Area: 36%	View item

Copper Rod

Line Number & Material	Diameter	Purity	Description
CU5133 Copper Rod	6.35 mm	99.99+%	Temper hard drawn OFHC C110.	View item
CU5135 Copper Rod	9.52 mm	99.99+%	Temper hard drawn OFHC C110.	View item
CU5130 Copper Rod	12.7 mm	99.99+%	Temper hard drawn OFHC C110.	View item
CU5163 Copper Rod	16 mm	99.99+%	Temper hard drawn OFHC C110.	View item
CU5131 Copper Rod	25 mm	99.99+%	Temper hard drawn OFHC C110.	View item
CU5132 Copper Rod	50 mm	99.99%	Temper hard drawn OFHC C110.	View item
CU5129 Copper Rod	80 mm	99.99+%	Temper hard drawn OFHC C110.	View item
